Product Details
Boasting some impressive features the ZJ Longarm Kit is a comprehensive package including everything needed for a great suspension lift while maintaining the vehicle`s crucial center of gravity. The kit includes adjustable high-clearance X-Flex upper and lower control arms with Clevite bushings featuring X-Flex joints. This lift kit features high-clearance components with a front y-link and rear 4-link control arm design. This promotes extreme axle flex while keeping pinion angles optimized.
Part Number: RC-90200U
Includes:
FRONT: Adjustable upper control arms
Adjustable lower control arms
Crossmember
Transfer case skid plate
Sway-bar quick disconnects
3-IN. Bumpstops
Hardware
REAR: Adjustable upper control arms
Adjustable lower control arms
Long arm frame brackets
Track bar bracket
Bumpstop brackets
Brake line brackets
Hardware
Benefits:
Aggressive appearance
Increased ground clearance
HD 0.25-IN. thick crossmember
Lower control arms feature high clearance design
Extreme travel long arms keep optimum alignment and give optimum articulation.
X-Flex control arm features:
Clevite brand OEM style rubber bushings.
Flex joints feature a massive 2.5-IN. diameter body and 1.25-IN. thread.
Fully greasable.
Upper joints pivot up to 20 degrees.
Lower joints pivot up to 35 degrees.
Specifics:
SKU: 90200U
Install Time:8-9 hours
Notes:
Does NOT fit AWD models.
Transfer case skid plate will NOT fit models equipped with 249 transfer case.
Exhaust will have to be cut and rerouted to make sure it is away from the moving components.
Models equipped with a CV style front driveshaft may result in driveshaft vibration. If this occurs
replacing the driveshaft
axle yoke and / or transfer case yoke will need to be performed to rid the vehicle of driveline vibration. CV Driveshaft Example
